SKU:

ZB5APA5C0

UPC:

3606489768546

MPN:

Condition:

New

Mercury Free:

Yes

Shape Of Signaling Unit Head:

round

Range Of Product:

Harmony XB5

Ambient Air Temperature For Operation:

-40-70 °C

Product Or Component Type:

head for non-illuminated push-button

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Overvoltage Category:

class II IEC 60536

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Product Compatibility:

not compatible with legend holder

Cad Overall Depth:

37 mm

Operator Additional Information:

clear boot

Rohs Exemption Information:

Yes

Protective Treatment:

TH

Cad Overall Width:

30 mm

Device Short Name:

ZB5

Nema Degree Of Protection:

NEMA 13 || NEMA 4X

Cad Overall Height:

30 mm

California Proposition 65:

WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Head Type:

standard

Bezel Material:

plastic colour plated grey

Vibration Resistance:

5 gn 2-500 Hz)IEC 60068-2-6

Ambient Air Temperature For Storage:

-40-70 °C

Ik Degree Of Protection:

IK03 IEC 50102

Mechanical Durability:

10000000 cycles

Mounting Diameter:

22 mm

China Rohs Regulation:

X

Operator Profile:

yellow flush, unmarked

Type Of Operator:

spring return

Shock Resistance:

30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Sale Per Indivisible Quantity:

1

Product Certifications:

UL Listed || CSA || BV || LROS (Lloyds register of shipping) || GL || DNV

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Ip Degree Of Protection:

IP66 IEC 60529 || IP67 IEC 60529
