Schneider Electric ZB5AT84TQ Blue Mushroom Latching Head Zb5At84 Sold

Schneider Electric ZB5AT84TQ Blue Mushroom Latching Head Zb5At84 Sold

Schneider Electric
SKU:
ZB5AT84TQ
|
UPC:
3389110885125
$40.40
(No reviews yet) Write a Review
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This Harmony ZB5AT84TQ is an Emergency stop, switching off head ZB5AT84 sold by 100. It is part of the range Harmony XB5 diameter 22mm modular plastic push buttons, switches, and pilot lights.
Additional Information
Bezel Material:
dark grey plastic
Vibration Resistance:
5 gn 2-500 Hz)IEC 60068-2-6
Reach Free Of Svhc:
Yes
Head Type:
standard
Cad Overall Depth:
56 mm
Mercury Free:
Yes
Sustainable Offer Status:
Green Premium product
Operator Profile:
red mushroom Ø 40 mm, unmarked
Nema Degree Of Protection:
NEMA 13 || NEMA 4X
Protective Treatment:
TH
Rohs Exemption Information:
Yes
Shape Of Signaling Unit Head:
round
Type Of Operator:
trigger action and mechanical latching
Device Short Name:
ZB5
Sale Per Indivisible Quantity:
10
Mechanical Durability:
300000 cycles
Range Of Product:
Harmony XB5
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Compatibility Code:
ZB5
Reset:
push-pull
Ip Degree Of Protection:
IP66 IEC 60529 || IP67 || IP69 || IP69K
Shock Resistance:
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Standards:
IEC 60947-5-5 || IEC 60364-5-53 || IEC 60204-1 || ISO 13850 || JIS C8201-5-1 || UL 508 || IEC 60947-5-1 || CSA C22.2 No 14 || IEC 60947-5-4 || IEC 60947-1 || GB 14048.5 || JIS C8201-1
Ambient Air Temperature For Storage:
-40-70 °C
Product Destination:
emergency stop push-button
Product Certifications:
UL Listed || GL || BV || CSA || LROS (Lloyds register of shipping) || DNV
Overvoltage Category:
class II IEC 60536
Resistance To High Pressure Washer:
7000000 Pa 55 °C 0.1 m
Station Name:
XALD 1 cut-out || XALK 1 cut-out
Product Or Component Type:
head for emergency stop push-button
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Mounting Diameter:
22 mm
California Proposition 65:
WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Warranty:
18 months
Ambient Air Temperature For Operation:
-40-70 °C
Electrical Composition Code:
C7 4 single front mounting || C8 4 single and double front mounting || C11 3 single front mounting || C15 1 single front mounting || SF1 3 single front mounting || SR1 3 single rear mounting || C10 4 single and double front mounting
Cad Overall Width:
40 mm
China Rohs Regulation:
X
Environmental Disclosure:
ENVPEP1710010EN
Cad Overall Height:
40 mm
Ik Degree Of Protection:
IK03 IEC 50102
Toxic Heavy Metal Free:
Yes
Circularity Profile:
ENVEOLI1710010EN
Datasheet:
View
