Schneider Electric ZB5AW363SC0 Blue Flush Illum Pb Head For Intgrl Led

(No reviews yet) Write a Review

Write a Review

Schneider Electric ZB5AW363SC0 Blue Flush Illum Pb Head For Intgrl Led

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

ZB5AW363SC0

UPC:

3606489770143

MPN:

Condition:

New

Cad Overall Width:

29 mm

Range Of Product:

Harmony XB5

Toxic Heavy Metal Free:

Yes

Protective Treatment:

TC

Net Weight:

0.017 kg

Important Message:

A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks

Nema Degree Of Protection:

NEMA 13 || NEMA 4X

Sale Per Indivisible Quantity:

1

Rohs Exemption Information:

Yes

Cad Overall Depth:

30 mm

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Reach Free Of Svhc:

Yes

Product Or Component Type:

head for illuminated push-button

China Rohs Regulation:

X

Mercury Free:

Yes

Operator Additional Information:

with grooved lens

Shock Resistance:

30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27

Cad Overall Height:

29 mm

Product Compatibility:

universal LED

Ip Degree Of Protection:

IP66 IEC 60529 || IP67

Standards:

IEC 60947-1 || JIS C8201-5-1 || GB 14048.5 || IEC 60947-5-4 || UL 508 || CSA C22.2 No 14 || IEC 60947-5-1 || JIS C8201-1

Environmental Characteristic:

high ambient lighting environment

Product Certifications:

LROS (Lloyds register of shipping) || BV || CSA || GL || UL Listed || DNV

Vibration Resistance:

5 gn 2-500 Hz)IEC 60068-2-6

Ambient Air Temperature For Storage:

-40-70 °C

Shape Of Signaling Unit Head:

round

Mounting Diameter:

22 mm

Reach Regulation:

Free of Substances of Very High Concern above the threshold

Group Of Product:

flush push integral LED

Marking:

unmarked

Electrical Composition Code:

M1 6 single front mounting integral LED || M2 6 single and double front mounting integral LED || M6 2 single front mounting integral LED and transformer || M10 2 single front mounting integral LED || MF1 2 single front mounting integral LED || MR1 2

Cap/Operator Or Lens Colour:

blue

Resistance To High Pressure Washer:

7000000 Pa 55 °C 0.1 m

Operator Profile:

blue flush, unmarked

Device Short Name:

ZB5

Station Name:

XALD 1...5 cut-outs || XALK 2...5 cut-outs

Device Presentation:

basic sub-assemblies

Mechanical Durability:

10000000 cycles

Ambient Air Temperature For Operation:

-40-70 °C

Ik Degree Of Protection:

IK05 IEC 62262

Overvoltage Category:

class II IEC 60536

Bezel Material:

plastic colour plated grey

Head Type:

standard

Type Of Operator:

spring return

Main Group:

illum push-button
