Schneider Electric ZB5AW553 Illuminated Pushbutton He
Schneider Electric
$46.50
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
This orange flush button head with clear boot provides an ergonomic interface for controlling your machines. It provides also a simple solution to prevent dirt and contaminants. It is easily installed and replaced on compatible complete push button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to illuminated head and clear colors. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It makes it ideal for operation in harsh environments.
- China Rohs Regulation:
- X
- Shape Of Signaling Unit Head:
- round
- Range Of Product:
- Harmony XB5
- Circularity Profile:
- ENVEOLI1710010EN
- Type Of Operator:
- spring return
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Cad Overall Width:
- 30 mm
- Marking:
- unmarked
- Cad Overall Depth:
- 37 mm
- Overvoltage Category:
- class II IEC 60536
- Ik Degree Of Protection:
- IK05 EN 50102
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67
- Standards:
- UL 508 || EN/IEC 60947-5-1 || CSA C22.2 No 14 || EN/IEC 60947-1 || EN/IEC 60947-5-4 || JIS C8201-5-1 || GB 14048.5 || JIS C8201-1
- Operator Profile:
- orange flush, unmarked
- Product Certifications:
- GL || DNV || UL Listed || LROS (Lloyds register of shipping) || CSA || BV
- Mounting Diameter:
- 22 mm
- Mechanical Durability:
- 10000000 cycles
- Cad Overall Height:
- 30 mm
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Sustainable Offer Status:
- Green Premium product
- Net Weight:
- 0.019 kg
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Main Group:
- illum push-button
- Product Compatibility:
- universal LED
- Rohs Exemption Information:
- Yes
- Sale Per Indivisible Quantity:
- 1
- Product Or Component Type:
- head for illuminated push-button
- Electrical Composition Code:
- M1 6 single front mounting integral LED || M2 6 single and double front mounting integral LED || M6 2 single front mounting integral LED and transformer || M10 2 single front mounting integral LED || MF1 2 single front mounting integral LED || MR1 2
- Bezel Material:
- dark grey plastic
- Warranty:
- 18 months
- Head Type:
- standard
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Ambient Air Temperature For Storage:
- -40-70 °C
- Operator Additional Information:
- clear boot
- Mercury Free:
- Yes
- Important Message:
- A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks
- Station Name:
- XALD 1...5 cut-outs || XALK 2...5 cut-outs
- Protective Treatment:
- TC
- Device Presentation:
- basic sub-assemblies
- Ambient Air Temperature For Operation:
- -40-70 °C
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Cap/Operator Or Lens Colour:
- orange
- Device Short Name:
- ZB5
- Group Of Product:
- flush push integral LED
- Environmental Disclosure:
- ENVPEP1710010EN
- Datasheet:
- View
