Schneider Electric ZB5AW7A9 Plastic Double Headed Pushbuttons Withou
This double head has 1 central white pilot light and is supplied without cap. This allows users to customize control functions with desired caps for their machines operations. It is easily installed and replaced on compatible complete push button units and contact blocks via snap-fit assembly. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66. It makes it ideal for operation in harsh environments.
- Head Type:
- standard
- Mounting Diameter:
- 22 mm
- Type Of Operator:
- spring return
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Cad Overall Depth:
- 30 mm
- Ambient Air Temperature For Operation:
- -25-70 °C
- Shape Of Signaling Unit Head:
- rectangular
- Nema Degree Of Protection:
- NEMA 13 || NEMA 4X
- Product Or Component Type:
- head for illuminated double-headed push-button
- Device Presentation:
- basic sub-assemblies
- Ip Degree Of Protection:
- IP66 || IP67 || IP69 || IP69K
- Warranty:
- 18 months
- Circularity Profile:
- ENVEOLI1710010EN
- Product Compatibility:
- integral LED
- Mercury Free:
- Yes
- Cad Overall Width:
- 30 mm
- Net Weight:
- 0.023 kg
- Environmental Disclosure:
- ENVPEP1710010EN
- Operator Profile:
- 2 flush push-buttons - 1 central pilot light
- Sale Per Indivisible Quantity:
- 1
- Ambient Air Temperature For Storage:
- -40-70 °C
- Cad Overall Height:
- 50 mm
- Bezel Material:
- dark grey plastic
- Mechanical Durability:
- 1000000 cycles
- Station Name:
- XALD 1 cut-out
- Vibration Resistance:
- 5 gn 2-500 Hz)IEC 60068-2-6
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Reach Free Of Svhc:
- Yes
- Operators Description:
- black pushes without cap
- Device Short Name:
- ZB5
- Range Of Product:
- Harmony XB5
- Standards:
- UL 508 || JIS C8201-5-1 || EN/IEC 60947-5-4 || CSA C22.2 No 14 || EN/IEC 60947-5-1 || EN/IEC 60947-1 || JIS C8201-1
- Rohs Exemption Information:
- Yes
- Electrical Shock Protection Class:
- class II IEC 60536
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Operator Profile:
- without cap
- Toxic Heavy Metal Free:
- Yes
- Product Certifications:
- BV || UL Listed || CSA || LROS (Lloyds register of shipping) || DNV || GL
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- China Rohs Regulation:
- X
- Sustainable Offer Status:
- Green Premium product
- Ik Degree Of Protection:
- IK05 IEC 50102
