Schneider Electric ZB5FH3C0 Flsmntd Green Proj Pb Head Push Push
Schneider Electric
$29.30
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric ZB5FH3C0 Flsmntd Green Proj Pb Head Push Push
This 30.5 mm push-button head provides an ergonomic interface for controlling your machine. It is easily installed and replaced on compatible complete push-button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to its clear color. It is vibration resistant, impact resistant, high pressure washer resistant and dust resistant thanks to its IP67, IP66 protection, making it ideal for operation in harsh environments.
- Operator Profile:
- green projecting, unmarked
- Device Presentation:
- basic element
- Cad Overall Height:
- 37 mm
- Mechanical Durability:
- 500000 cycles
- Mounting Diameter:
- 30.5 mm
- Ambient Air Temperature For Operation:
- -40-70 °C
- Product Or Component Type:
- head for non-illuminated push-button
- Type Of Operator:
- push-push
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Net Weight:
- 0.031 kg
- Warranty:
- 18 months
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Cad Overall Width:
- 37 mm
- Rohs Exemption Information:
- Yes
- Bezel Material:
- plastic colour plated grey
- Mercury Free:
- Yes
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Device Short Name:
- ZB5F
- Sale Per Indivisible Quantity:
- 1
- Protective Treatment:
- TH
- Overvoltage Category:
- class II IEC 60536
- Cad Overall Depth:
- 32 mm
- Shape Of Signaling Unit Head:
- round
- Range Of Product:
- Harmony XB5
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 IEC 60529
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 || 25 gn 6 ms) 1000 shocks on each axis IEC 60068-2-27
- Product Compatibility:
- ZBYF... || ZBZF32 || ZBZF33 || ZB5AZ
- China Rohs Regulation:
- X
- Product Certifications:
- UL Listed || CSA
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Vibration Resistance:
- 5 gn 10-500 Hz)IEC 60068-2-6 || 2 mm peak to peak 2-10 Hz)IEC 60068-2-6
- Head Type:
- built-in-flush
- Ambient Air Temperature For Storage:
- -40-70 °C
- Electrical Composition Code:
- C11 3 single front mounting || C15 1 single front mounting || SF1 3 single front mounting || C9 3 single front mounting
- Ik Degree Of Protection:
- IK03 IEC 50102
