Schneider Electric ZB5FL5 Flush Mounted Yellow Projecting Pushbutt
Schneider Electric
$13.30
(No reviews yet)
Write a Review
Write a Review
Schneider Electric
Schneider Electric ZB5FL5 Flush Mounted Yellow Projecting Pushbutt
This 30.5 mm push-button head provides an ergonomic interface for controlling your machine. It is easily installed and replaced on compatible complete push-button units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to its clear color. It is vibration resistant, impact resistant, high pressure washer resistant and dust resistant thanks to its IP69 protection, making it ideal for operation in harsh environments.
- Ambient Air Temperature For Operation:
- -40-70 °C
- Device Short Name:
- ZB5
- Product Or Component Type:
- head for non-illuminated push-button
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Environmental Disclosure:
- ENVPEP1710010EN
- Shape Of Signaling Unit Head:
- round
- Bezel Material:
- dark grey plastic
- Device Presentation:
- basic element
- Warranty:
- 18 months
- Product Certifications:
- GL || BV || CSA || LROS (Lloyds register of shipping) || DNV || UL Listed
- Cad Overall Height:
- 37 mm
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Ik Degree Of Protection:
- IK03 IEC 50102
- Ambient Air Temperature For Storage:
- -40-70 °C
- Range Of Product:
- Harmony XB5
- Cad Overall Width:
- 37 mm
- Head Type:
- built-in-flush
- Mounting Diameter:
- 30.5 mm
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27 || 25 gn 6 ms) 1000 shocks on each axis IEC 60068-2-27
- Electrical Composition Code:
- C1 9 single front mounting || C2 9 single and double front mounting || C11 3 single front mounting || C15 1 single front mounting || SF1 3 single front mounting
- Vibration Resistance:
- 5 gn 10-500 Hz)IEC 60068-2-6 || 2 mm peak to peak 2-10 Hz)IEC 60068-2-6
- Sustainable Offer Status:
- Green Premium product
- Protective Treatment:
- TH
- Cad Overall Depth:
- 32 mm
- Standards:
- JIS C8201-5-1 || EN/IEC 60947-5-1 || CSA C22.2 No 14 || EN/IEC 60947-1 || EN/IEC 60947-5-4 || UL 508 || JIS C8201-1
- China Rohs Regulation:
- X
- Net Weight:
- 0.031 kg
- Overvoltage Category:
- class II IEC 60536
- Product Compatibility:
- ZBYF... || ZBZF32 || ZBZF33 || ZB5AZ
- Mercury Free:
- Yes
- Rohs Exemption Information:
- Yes
- Circularity Profile:
- ENVEOLI1710010EN
- Ip Degree Of Protection:
- IP66 IEC 60529 || IP67 IEC 60529 || IP69 IEC 60529 || IP69K ISO 20653 || Type 13 UL 50 E || Type 12 UL 50 E || Type 4 UL 50 E || Type 4X UL 50 E
- Mechanical Durability:
- 10000000 cycles
- Operator Profile:
- yellow projecting, unmarked
- Sale Per Indivisible Quantity:
- 1
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Type Of Operator:
- spring return
- Datasheet:
- View
