Schneider Electric ZB6AF6 Illuminated Pushbut To N Head Diam 16 Bl
This Harmony ZB6AF6 is a blue flush illuminated push button head, latching for integral LED. It is part of the range Harmony XB6 diameter 16mm monolithic plastic push buttons, switches, and pilot lights.
- Product Or Component Type:
- head for illuminated push-button
- Toxic Heavy Metal Free:
- Yes
- Net Weight:
- 0.016 kg
- Product Certifications:
- CSA || CCC || UL || GOST
- China Rohs Regulation:
- X
- Device Short Name:
- ZB6
- Mechanical Durability:
- 300000 cycles
- Mounting Diameter:
- 16 mm
- Ip Degree Of Protection:
- IP65 IEC 60529
- Standards:
- JIS C8201-5-1 || EN/IEC 60947-1 || CSA C22.2 No 14 || UL 508 || EN/IEC 60947-5-1 || JIS C 852 || EN/IEC 60947-5-5 || JIS C8201-1
- Ambient Air Temperature For Storage:
- -40-70 °C
- Product Compatibility:
- integral LED
- Environmental Disclosure:
- ENVPEP1710010EN
- Shape Of Signaling Unit Head:
- round
- Protective Treatment:
- TC
- Shock Resistance:
- 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
- Ambient Air Temperature For Operation:
- -25-70 °C
- Bezel Material:
- plastic
- Nema Degree Of Protection:
- NEMA 13 UL 50 || NEMA 4 UL 50 || NEMA 4X UL 50 || NEMA 13 CSA C22.2 No 94 || NEMA 4 CSA C22.2 No 94 || NEMA 4X CSA C22.2 No 94
- Sustainable Offer Status:
- Green Premium product
- Vibration Resistance:
- +/- 3 mm 2-500 Hz)IEC 60068-2-6 || 5 gn 2-500 Hz)IEC 60068-2-6
- Range Of Product:
- Harmony XB6
- Mercury Free:
- Yes
- Cad Overall Depth:
- 33 mm
- Electrical Shock Protection Class:
- class II IEC 61140
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Reach Free Of Svhc:
- Yes
- Operator Profile:
- blue flush, unmarked
- Cad Overall Height:
- 18 mm
- Type Of Operator:
- latching
- Reach Regulation:
- Free of Substances of Very High Concern above the threshold
- Sale Per Indivisible Quantity:
- 1
- Rohs Exemption Information:
- Yes
- Warranty:
- 18 months
- Cad Overall Width:
- 18 mm
- Resistance To High Pressure Washer:
- 7000000 Pa 55 °C 0.1 m
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Circularity Profile:
- ENVEOLI1710010EN
