Schneider Electric ZB6EB6B Body For Pilot Light Zb6 Blue Integral L

(No reviews yet) Write a Review

Write a Review

Schneider Electric ZB6EB6B Body For Pilot Light Zb6 Blue Integral L

Rating Required Select Rating 1 star (worst) 2 stars 3 stars (average) 4 stars 5 stars (best)

Name

Email Required

Review Subject Required

Comments Required

SKU:

ZB6EB6B

UPC:

3.38911E+12

MPN:

Condition:

New

Product Or Component Type:

complete body for pilot lights

Operating Position:

any position

Eu Rohs Directive:

Pro-active compliance (Product out of EU RoHS legal scope)

Reach Regulation:

Reference contains Substances of Very High Concern above the threshold

Light Source Colour:

blue

Environmental Disclosure:

ENVPEP1710010EN

Surge Withstand:

1 kV in contact IEC 61000-4-5 || 2 kV in free air IEC 61000-4-5

Net Weight:

0.003 kg

Resistance To Electrostatic Discharge:

6 kV on contact (on metal parts) IEC 61000-2-6 || 8 kV in free air (in insulating parts) IEC 61000-2-6

Warranty:

18 months

Vibration Resistance:

+/- 3 mm 2-500 Hz)IEC 60068-2-6 || 5 gn 2-500 Hz)IEC 60068-2-6

Standards:

CSA C22.2 No 14 || JIS C 4520 || IEC 60947-1 || IEC 60947-5-1 || JIS C 852 || IEC 60947-5-5 || UL 508

Connections - Terminals:

Faston connectors 2.8 x 0.5 mm

Ambient Air Temperature For Operation:

-25-70 °C

Light Source:

LED

Weee:

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.

Protective Treatment:

TC

[Uimp] Rated Impulse Withstand Voltage:

4 kV IEC 60947-1

[Ui] Rated Insulation Voltage:

250 V 3)IEC 60947-1

Cad Overall Depth:

58 mm

Cad Overall Height:

14 mm

Mercury Free:

Yes

Electrical Shock Protection Class:

class II IEC 61140

Terminals Description Iso N°1:

(+ -)PL

Bulb Base:

integral LED

Device Short Name:

ZB6

Sustainable Offer Status:

Green Premium product

Range Of Product:

Harmony XB6

Current Consumption:

15 mA

Electromagnetic Emission:

class B IEC 55011

Product Certifications:

GOST || CCC || UL || CSA

Circularity Profile:

ENVEOLI1710010EN

[Us] Rated Supply Voltage:

12...24 V AC/DC

Shock Resistance:

30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27

California Proposition 65:

WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

Light Block Supply:

direct

Ambient Air Temperature For Storage:

-40-70 °C

Resistance To Electromagnetic Fields:

10 V/m IEC 61000-4-3

Sale Per Indivisible Quantity:

5

Signalling Type:

steady

Rohs Exemption Information:

Yes

Supply Voltage Limits:

6-30 V AC/DC

China Rohs Regulation:

X

Resistance To Fast Transients:

2 kV IEC 61000-4-4
