Schneider Electric ZBE1024 Nc Connector Contact

Schneider Electric ZBE1024 Nc Connector Contact

Schneider Electric
SKU:
ZBE1024
|
UPC:
3389110089509
Availability:
Contact us to confirm availability and lead times.
$20.80
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This Harmony ZB, single contact block uses plug-in terminals. It is compatible with Harmony XB4 and XB5 control and signaling units. This contact block allows fast and easy replacement and configuration of your push buttons and selector switches. It is easily installed and replaced on XB4 and XB5 complete push-button units and selector switches and connects to control circuits with simple plug-in connections. It protects operators from unexpected contact with live circuits thanks to its IP20 protection index. 1 million cycle high endurance under 6A load allows less maintenance and damage in your installation. It has clear color scheme for NO and NC contact block types. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.
Additional Information
Connections - Terminals:
plug-in connector
Contact Operation:
slow-break
[Ie] Rated Operational Current:
3 A 240 V, AC-15, A300 IEC 60947-5-1 || 6 A 120 V, AC-15, A300 IEC 60947-5-1 || 0.1 A 250 V, DC-13, R300 IEC 60947-5-1 || 0.22 A 125 V, DC-13, R300 IEC 60947-5-1
Reach Regulation:
Free of Substances of Very High Concern above the threshold
[Ui] Rated Insulation Voltage:
250 V 3)IEC 60947-1
Net Weight:
0.011 kg
Positive Opening:
with IEC 60947-5-1 appendix K
China Rohs Regulation:
X
Toxic Heavy Metal Free:
Yes
Warranty:
18 months
Operating Travel:
1.5 mm NC changing electrical state) || 4.3 mm total travel)
Environmental Disclosure:
ENVPEP1808008EN
Protective Treatment:
TH
Reach Free Of Svhc:
Yes
Contacts Material:
silver alloy (Ag/Ni)
Rohs Exemption Information:
Yes
Ambient Air Temperature For Storage:
-40-70 °C
Electrical Composition Code:
C11 3 ) || C14 2 ) || M10 2 )
California Proposition 65:
WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Sale Per Indivisible Quantity:
5
Mechanical Durability:
10000000 cycles
Device Short Name:
ZBE
[Ith] Conventional Free Air Thermal Current:
10 A IEC 60947-5-1
Vibration Resistance:
5 gn 2-500 Hz)IEC 60068-2-6
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Operating Force:
2 N NC changing electrical state
Product Certifications:
GL || CSA || BV || LROS (Lloyds register of shipping) || DNV || UL
Mercury Free:
Yes
Ip Degree Of Protection:
IP20 IEC 60529
Ambient Air Temperature For Operation:
-40-70 °C
[Uimp] Rated Impulse Withstand Voltage:
4 kV IEC 60947-1
Standards:
CSA C22.2 No 14 || UL 508 || IEC 60947-1 || IEC 60947-5-4 || JIS C8201-5-1 || IEC 60947-5-1 || JIS C8201-1
Contacts Type And Composition:
1 NC
Range Of Product:
Harmony XB5 || Harmony XB4
Contacts Usage:
standard contacts
Shock Resistance:
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Device Presentation:
basic element
Mounting Of Block:
front mounting
Sustainable Offer Status:
Green Premium product
Product Or Component Type:
contact block
Contact Block Type:
single
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Short-Circuit Protection:
4 A cartridge fuse gG IEC 60947-5-1
Electrical Durability:
1000000 cycles, AC-15, 1 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 1.5 A 120 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, AC-15, 3 A 24 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C || 1000000 cycles, DC-13
Circularity Profile:
ENVEOLI1808008EN
