Schneider Electric ZBE702 Control Button Contact Block Zbe Diam 22

Schneider Electric ZBE702 Control Button Contact Block Zbe Diam 22

Schneider Electric
SKU:
ZBE702
|
UPC:
3389110089523
Availability:
Contact us to confirm availability and lead times.
$20.80
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This Harmony ZB, single contact block uses PCB terminals. It is compatible with Harmony XB4 and XB5 control and signaling units. This contact block allows fast and easy replacement and configuration of your push buttons and selector switches. It is easily installed and replaced on XB4 and XB5 complete push-button units and selector switches and connects to control circuits with simple PCB connections. It protects operators from unexpected contact with live circuits thanks to its IP20 protection index. 1 million cycle high endurance under 6A load allows less maintenance and damage in your installation. It has clear color scheme for NO and NC contact block types. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.
Additional Information
Contact Block Type:
single
Ambient Air Temperature For Storage:
-40-70 °C
Contact Operation:
slow-break
Product Or Component Type:
contact block
Protective Treatment:
TH
Mechanical Durability:
5000000 cycles
Device Short Name:
ZBE
Short-Circuit Protection:
4 A cartridge fuse gG IEC 60947-5-1
Environmental Disclosure:
ENVPEP1808008EN
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
[Ui] Rated Insulation Voltage:
250 V 3)IEC 60947-1
Product Certifications:
CSA || UL || GL || DNV || LROS (Lloyds register of shipping) || BV
Ip Degree Of Protection:
IP20 IEC 60529
Range Of Product:
Harmony XB4 || Harmony XB5
Toxic Heavy Metal Free:
Yes
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
[Uimp] Rated Impulse Withstand Voltage:
4 kV IEC 60947-1
Shock Resistance:
30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
Contacts Material:
silver alloy (Ag/Ni)
China Rohs Regulation:
X
Positive Opening:
with IEC 60947-5-1 appendix K
Operating Travel:
1.5 mm NC changing electrical state) || 4.3 mm total travel)
[Ie] Rated Operational Current:
3 A 120 V, AC-15, B300 IEC 60947-5-1 || 1.5 A 240 V, AC-15, B300 IEC 60947-5-1 || 0.1 A 250 V, DC-13, R300 IEC 60947-5-1 || 0.22 A 125 V, DC-13, R300 IEC 60947-5-1
Operating Force:
2 N NC changing electrical state
Reach Free Of Svhc:
Yes
Warranty:
18 months
Net Weight:
0.011 kg
Connections - Terminals:
pins for printed circuit board
Reach Regulation:
Free of Substances of Very High Concern above the threshold
Sustainable Offer Status:
Green Premium product
[Ith] Conventional Free Air Thermal Current:
6 A IEC 60947-5-1
California Proposition 65:
WARNING: This product can expose you to chemicals including: Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Standards:
IEC 60947-5-4 || JIS C8201-5-1 || UL 508 || IEC 60947-5-1 || CSA C22.2 No 14 || IEC 60947-1 || JIS C8201-1
Contacts Usage:
standard contacts
Vibration Resistance:
5 gn 2-500 Hz)IEC 60068-2-6
Contacts Type And Composition:
1 NC
Ambient Air Temperature For Operation:
-25-70 °C
Sale Per Indivisible Quantity:
10
Circularity Profile:
ENVEOLI1808008EN
Mercury Free:
Yes
Rohs Exemption Information:
Yes
