Schneider Electric ZBVB19 Close Tag Connect. Led Bl Pack of 5
This Harmony ZB, white light block operates with a universal LED. It is supplied with 24V AC/DC and uses lugs terminals. It has a plastic body. It is compatible with Harmony XB4 and XB5. This light block allows fast and easy replacement and configuration of your signaling units. It is easily installed and replaced on compatible illuminated push-button or selector switch units via clip together assembly and connected with simple screw-clamp connections. It enables visual distinction of signaling units via illumination by universal LED. It protects operators from unexpected contact with live circuits thanks to its IP20 protection index. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.
- Sustainable Offer Status:
- Green Premium product
- Range Of Product:
- Harmony XB4 || Harmony XB5
- Signalling Type:
- steady
- Sale Per Indivisible Quantity:
- 5
- Resistance To Fast Transients:
- 2 kV IEC 61000-4-4
- [Us] Rated Supply Voltage:
- 24 V AC/DC 50/60 Hz
- Ambient Air Temperature For Operation:
- -40-70 °C
- Electrical Composition Code:
- M1 || M2 || M3 || M4 || M5 || M6 || M10 || MF1 || P1 || P2 || PF1
- California Proposition 65:
- WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
- Net Weight:
- 0.017 kg
- Protective Treatment:
- TH
- Circularity Profile:
- ENVEOLI1808008EN
- Reach Regulation:
- Reference contains Substances of Very High Concern above the threshold
- Supply Voltage Limits:
- 19.2-30 V DC || 21.6-26.4 V AC
- Light Source Colour:
- white
- Eu Rohs Directive:
- Pro-active compliance (Product out of EU RoHS legal scope)
- Warranty:
- 18 months
- Standards:
- IEC 60947-5-4 || IEC 60947-5-1 || IEC 60947-1 || JIS C8201-5-1 || CSA C22.2 No 14 || IEC 60947-5-5 || UL 508 || JIS C8201-1
- Ambient Air Temperature For Storage:
- -40-70 °C
- Rohs Exemption Information:
- Yes
- Product Or Component Type:
- light block
- Resistance To Electromagnetic Fields:
- 10 V/m IEC 61000-4-3
- Ip Degree Of Protection:
- IP20 IEC 60529
- Environmental Disclosure:
- ENVPEP1808008EN
- Weee:
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
- Mercury Free:
- Yes
- Resistance To Electrostatic Discharge:
- 6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2
- [Us] Rated Supply Voltage:
- 24 V
- Light Block Supply:
- direct
- Service Life:
- 100000 h at rated voltage and 25 °C
- Current Consumption:
- 18 mA
- Surge Withstand:
- 1 kV IEC 61000-4-5
- China Rohs Regulation:
- X
- Bulb Base:
- integral LED
- Electromagnetic Emission:
- class B IEC 55011
- Device Short Name:
- ZBV
- Connections - Terminals:
- screw terminals for lug
- Mounting Of Block:
- front mounting
- Light Source:
- universal LED
