Schneider Electric ZBVB37 Light Block Diam 22 Integral Led Green 2 Pack of 5

Schneider Electric ZBVB37 Light Block Diam 22 Integral Led Green 2 Pack of 5

Schneider Electric
SKU:
ZBVB37
|
UPC:
3389110090376
$104.00
Condition:
New
$1200 Minimum Order for Non-stock Items or $60 Addl Schneider Handling Fee Applies
Current Stock:
Description
This Harmony ZB, green light block operates with an integral LED. It is supplied with 24V AC/DC. It is compatible with Harmony XB4 and XB5. This light block allows fast and easy replacement and configuration of your signaling units. It is easily installed and replaced on compatible illuminated push-button or selector switch units via clip together assembly and connected with simple screw-clamp connections. It enables visual distinction of signaling units via illumination by integral LED. It protects operators from unexpected contact with live circuits thanks to its IP20 protection index. Its wide range of operating temperatures from -40°C to 70°C allows versatility in usage of product.
Additional Information
Current Consumption:
18 mA
Light Source Colour:
green
Eu Rohs Directive:
Pro-active compliance (Product out of EU RoHS legal scope)
Circularity Profile:
ENVEOLI2302007EN
Standards:
EN/IEC 60947-5-4 || EN/IEC 60947-1 || EN/IEC 60947-5-1 || CSA C22.2 No 14 || JIS C8201-5-1 || UL 508 || EN/IEC 60947-5-5 || JIS C8201-1
Resistance To Electromagnetic Fields:
10 V/m IEC 61000-4-3
California Proposition 65:
WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Weee:
The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Reach Regulation:
Reference contains Substances of Very High Concern above the threshold
China Rohs Regulation:
X
Supply Voltage Limits:
19.2-30 V DC || 21.6-26.4 V AC
Warranty:
18 months
Protective Treatment:
TH
Range Of Product:
Harmony XB4 || Harmony XB5
Ip Degree Of Protection:
IP20 IEC 60529
Device Short Name:
ZBV
Ambient Air Temperature For Operation:
-40-70 °C
Net Weight:
0.004 kg
Signalling Type:
steady
Electromagnetic Emission:
class B IEC 55011
Surge Withstand:
1 kV IEC 61000-4-5
Electrical Composition Code:
M1 || M2 || M3 || M4 || M5 || M6 || M10 || MF1 || P1 || P2 || PF1
[Us] Rated Supply Voltage:
24 V AC/DC 50/60 Hz
Service Life:
100000 h at rated voltage and 25 °C
Light Source:
protected LED
Rohs Exemption Information:
Yes
Sale Per Indivisible Quantity:
5
Ambient Air Temperature For Storage:
-40-70 °C
Environmental Disclosure:
ENVPEP2302007EN
Resistance To Fast Transients:
2 kV IEC 61000-4-4
Sustainable Offer Status:
Green Premium product
Light Block Supply:
direct
Mounting Of Block:
front mounting
Product Or Component Type:
light block
[Us] Rated Supply Voltage:
24 V
Bulb Base:
integral LED
Resistance To Electrostatic Discharge:
6 kV on contact (on metal parts) IEC 61000-4-2 || 8 kV in free air (in insulating parts) IEC 61000-4-2
Connections - Terminals:
pins for printed circuit board
