SensoPart FE 10-RL-NS-KM4 Through-beam laser sensor
Sensopart
The SensoPart FE 10-RL-NS-KM4 Through-beam Laser Sensor is a high-performance photoelectric sensor designed for precise detection tasks. With a working distance ranging from 1000 mm to 4000 mm, this sensor is ideal for applications requiring long-range detection. It features a red Class 1 laser light source and operates with a velocity of 4000 Hz, ensuring rapid and accurate response times. The sensor is equipped with a teach-in adjustment for easy setup and configuration.
This model includes an NPN switching output and is designed to withstand harsh environments with an IP 67 enclosure rating. It operates efficiently within a temperature range of -20°C to +50°C. The connection is facilitated by a 200 mm pigtail with a 4-pin M8 connector, ensuring secure and reliable connectivity.
For more detailed information, you can access the datasheet, catalog, brochure, operating instructions, and CAD files through the provided links. This sensor is part of the compact F10 series, measuring 21.1 x 14.6 x 8 mm, making it suitable for space-constrained installations.
- Sensor principle:
- Photoelectric through-beam sensor (sender/receiver)
- Series:
- F10 (21,1 x 14,6 x 8 mm)
- Working distance min. [mm]:
- 1000
- Working distance max. [mm]:
- 4000
- Velocity [Hz]:
- 4000
- Adjustment:
- Teach-in
- Light source:
- Laser, red (Class 1)
- Switching output:
- NPN
- Temperature range [°C]:
- -20 ... +50
- Connection type:
- Pigtail, plug M8, 4-wire, 200 mm
- Enclosure rating:
- IP 67
