SensoPart FE 55-RL-PS-L4 Through-beam laser sensor
Sensopart
The SensoPart FE 55-RL-PS-L4 is a high-performance through-beam laser sensor designed for precise detection over distances ranging from 0 to 25 meters. This receiver unit utilizes a Class 1 red laser light source, ensuring safe and accurate operation. With a robust IP69K and IP67 enclosure rating, it is built to withstand harsh environments, making it ideal for industrial applications. The sensor features a teach-in adjustment for easy setup and a PNP switching output for reliable signal processing. It operates efficiently within a temperature range of -20 to +60°C and connects via a 4-pin M12 plug. The compact design, part of the F55 series, measures 50 x 50.1 x 23 mm, and supports a high velocity of 3500 Hz, ensuring rapid response times. For more detailed information, refer to the datasheet, catalog, brochure, operating instructions, and CAD files available through the provided links.
- Sensor principle:
- Photoelectric through-beam sensor (sender/receiver)
- Series:
- F55 (50 x 50,1 x 23 mm)
- Working distance min. [mm]:
- 0
- Working distance max. [mm]:
- 25000
- Velocity [Hz]:
- 3500
- Adjustment:
- Teach-in
- Light source:
- Laser, red (Class 1)
- Switching output:
- PNP
- Temperature range [°C]:
- -20 ... +60
- Connection type:
- Plug M12, 4-pin
- Enclosure rating:
- IP69K, IP 67
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
