SensoPart FR 25-RLO2-PNSL-M4 Autocollimation laser photoelectric retro-reflective sensor
Sensopart
The SensoPart FR 25-RLO2-PNSL-M4 is a high-performance autocollimation laser photoelectric retro-reflective sensor designed for precision and reliability. With a working distance ranging from 0 to 4 meters, this sensor utilizes a red Class 1 laser light source for accurate detection. It features a teach-in adjustment method and an auto-detect switching output that supports both PNP and NPN configurations. Operating at a velocity of 4 kHz, it ensures rapid response times suitable for dynamic applications. The sensor is equipped with an IO-Link interface for seamless integration and communication. Its robust design includes an IP69 enclosure rating, making it suitable for harsh environments with a temperature range of -20 to +60°C. The connection is facilitated through a 4-pin M8 plug, ensuring secure and reliable connectivity. For more detailed information, you can access the datasheet, catalog, brochure, operating instructions, and CAD files through the provided links.
- Sensor principle:
- Photoelectric retro-reflective sensor
- Series:
- F25 (34 x 20 x 12 mm)
- Working distance min. [mm]:
- 0
- Working distance max. [mm]:
- 4000
- Velocity [Hz]:
- 4000
- Interface:
- IO-Link
- Adjustment:
- Teach-in
- Light source:
- Laser, red (Class 1)
- Switching output:
- PNP/NPN (auto detect)
- Temperature range [°C]:
- -20 ... +60
- Connection type:
- Plug M8, 4-pin
- Enclosure rating:
- IP69
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
