SensoPart FR 25-RL-PS-K4 Laser retroreflective photoelectric sensor
Sensopart
The SensoPart FR 25-RL-PS-K4 is a high-performance laser retroreflective photoelectric sensor designed for precise detection tasks. With a working distance ranging from 0.1 to 15 meters, this sensor utilizes a red laser light source (Class 1) for accurate and reliable operation. It features a teach-in adjustment method, allowing for easy setup and configuration. The sensor operates with a PNP switching output and is equipped with a 2-meter, 4-wire cable for connectivity.
Built to withstand harsh environments, the sensor boasts an IP69K enclosure rating, ensuring protection against dust and high-pressure water jets. It operates efficiently within a temperature range of -20 to +60°C, making it suitable for various industrial applications. The sensor's compact design, part of the F25 series, measures 34 x 20 x 12 mm, and it connects via a metal plug M8, 3-pin.
For further technical details, you can access the datasheet, catalog, brochure, operating instructions, and CAD files through the provided links. This sensor is ideal for applications requiring high-speed detection, with a velocity of up to 4000 Hz.
- Sensor principle:
- Photoelectric retro-reflective sensor
- Series:
- F25 (34 x 20 x 12 mm)
- Working distance min. [mm]:
- 100
- Working distance max. [mm]:
- 13000
- Velocity [Hz]:
- 4000
- Adjustment:
- Teach-in
- Light source:
- Laser, red (Class 1)
- Switching output:
- PNP
- Temperature range [°C]:
- -20 ... +60
- Connection type:
- Metal plug M8, 3-pin
- Enclosure rating:
- IP69K
