SensoPart FR 55-R-PS-K4 Photoelectric retro-reflective sensor
Sensopart
The SensoPart FR 55-R-PS-K4 is a high-performance photoelectric retro-reflective sensor designed for precise detection tasks. It operates within a working distance range of 0.3 to 12 meters, utilizing a red LED light source for reliable performance. The sensor features a teach-in adjustment for easy setup and configuration, and it outputs a PNP switching signal. With a robust enclosure rating of IP69K and IP67, it is well-suited for harsh environments, offering protection against dust and high-pressure water jets. The sensor is equipped with a 3-meter, 4-wire cable for flexible installation. It operates efficiently within a temperature range of -20 to +60°C and supports a velocity of 600 Hz, making it ideal for fast-paced industrial applications. For more detailed information, you can access the datasheet, catalog, brochure, operating instructions, and CAD files through the provided links.
- Sensor principle:
- Photoelectric retro-reflective sensor
- Series:
- F55 (50 x 50,1 x 23 mm)
- Working distance min. [mm]:
- 300
- Working distance max. [mm]:
- 12000
- Velocity [Hz]:
- 600
- Adjustment:
- Teach-in
- Light source:
- LED, red
- Switching output:
- PNP
- Temperature range [°C]:
- -20 ... +60
- Connection type:
- Cable, 4-wire, 3 m
- Enclosure rating:
- IP69K, IP 67
