SensoPart FS 10-RL-K4 Through-beam laser sensor
Sensopart
The SensoPart FS 10-RL-K4 Through-beam Laser Sensor is a high-performance photoelectric sensor designed for precise detection tasks. With a working distance ranging from 0 to 4000 mm, this sensor is ideal for applications requiring reliable long-range detection. It features a red Class 1 laser light source, ensuring accurate and safe operation. The sensor operates at a velocity of 4000 Hz, making it suitable for high-speed applications.
The FS 10-RL-K4 is equipped with a 2-meter, 4-wire cable for easy installation and connectivity. Its compact design, measuring 21.1 x 14.6 x 8 mm, allows for seamless integration into various setups. The sensor is built to withstand harsh environments, with an enclosure rating of IP 67 and a temperature range of -20 to +50°C.
For ease of use, the sensor includes a teach-in adjustment feature, simplifying setup and calibration. Comprehensive documentation is available, including datasheets, catalogs, brochures, operating instructions, and CAD files, providing all necessary information for installation and operation.
This sensor is an excellent choice for industries requiring precise and reliable detection solutions.
- Sensor principle:
- Photoelectric through-beam sensor (sender/receiver)
- Series:
- F10 (21,1 x 14,6 x 8 mm)
- Working distance min. [mm]:
- 0
- Working distance max. [mm]:
- 4000
- Velocity [Hz]:
- 4000
- Adjustment:
- Teach-in
- Light source:
- Laser, red (Class 1)
- Temperature range [°C]:
- -20 ... +50
- Connection type:
- Cable, 4-wire, 2 m
- Enclosure rating:
- IP 67
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
