SensoPart FT 25-BH-PNSL-KM4 Photoelectric diffuse sensor with background suppression
Sensopart
The SensoPart FT 25-BH-PNSL-KM4 is engineered for precision in detection tasks, featuring advanced background suppression technology. It operates effectively within a working distance of 1 to 200 mm, utilizing blue LED light to ensure enhanced accuracy. The sensor is designed for user-friendly setup with a teach-in adjustment and an auto-detect function for PNP/NPN switching output. Built to withstand harsh environments, it boasts an IP69K enclosure rating and functions efficiently in temperatures ranging from -20 to +60°C. Seamless integration is facilitated by its IO-Link interface, while a 150 mm pigtail with a 4-pin M8 plug ensures secure connections. Compact yet powerful, this sensor is part of the F25 series, with dimensions of 34 x 20 x 12 mm, making it ideal for applications that demand reliable object detection and background suppression. For comprehensive details, refer to the datasheet, catalog, brochure, operating instructions, and CAD files available through the provided links.
- Sensor principle:
- Photoelectric diffuse sensor with Background Suppression
- Series:
- F25 (34 x 20 x 12 mm)
- Working distance min. [mm]:
- 0
- Working distance max. [mm]:
- 200
- Velocity [Hz]:
- 700
- Interface:
- IO-Link
- Adjustment:
- Teach-in
- Light source:
- LED, blue
- Switching output:
- PNP/NPN (auto detect)
- Temperature range [°C]:
- -20 ... +60
- Connection type:
- Pigtail, plug M8, 4-wire, 150 mm
- Enclosure rating:
- IP69K
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
