SensoPart FT 25-RLA-80-PNSUL-M4M Miniature laser distance sensor
Sensopart
The SensoPart FT 25-RLA-80-PNSUL-M4M Miniature Laser Distance Sensor is a compact and precise solution for distance measurement applications. With a working range of 20 to 100 mm and a resolution of 0.12 mm, this sensor utilizes a red Class 1 laser for accurate triangulation. It features a teach-in function and supports both PNP and NPN auto-detect switching outputs. The sensor offers an analog measurement output with a voltage range of 1 to 10 V and is equipped with an IO-Link interface for seamless integration.
Designed for durability, the sensor has an enclosure rating of IP67 and IP69K, ensuring protection against dust and water ingress. It operates efficiently within a temperature range of -20 to +60°C, with minimal temperature drift. The sensor's cubic design (34 x 20 x 12 mm) and metal plug M8 4-pin connection make it easy to install in various industrial environments.
For more detailed information, you can access the datasheet, catalog, brochure, operating instructions, and CAD files through the provided links. This sensor is ideal for applications requiring high precision and reliability in distance measurement.
- Linearity [mm]:
- 0.25
- Sensor principle:
- Distance sensor with triangulation
- Series:
- F25 (34 x 20 x 12 mm)
- Working distance min. [mm]:
- 20
- Working distance max. [mm]:
- 100
- Velocity [Hz]:
- 1000
- Interface:
- IO-Link
- Type:
- Cubic
- Light source:
- Laser, red (Class 1)
- Switching output:
- PNP/NPN (auto detect)
- Amount of swithing outputs:
- 1
- Resolution [mm]:
- 0.12
- Repeatability [mm]:
- 0.25
- Temperature range [°C]:
- -20 ... +60
- Temperature drift [%]:
- 0,1 mm / K
- Measurement output:
- Analog (voltage), IO-Link
- Connection type:
- Metal plug M8, 4-pin
- Enclosure rating:
- IP 67, IP69K
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
