SensoPart FT 10-B-RLF2-NS-E4 Diffuse laser sensor with background suppression, fixed focus
Sensopart
The SensoPart FT 10-B-RLF2-NS-E4 is a high-performance diffuse laser sensor designed for precision detection with background suppression and a fixed focus. It operates within a working distance range of 6 to 30 mm, making it ideal for applications requiring close-range sensing. The sensor features a compact design from the F10 series, measuring 21.1 x 14.6 x 8 mm, and utilizes a red Class 1 laser light source with a spot size of 1 x 3 mm. It offers a fast response time with a velocity of 1000 Hz and is equipped with an NPN switching output. The sensor is built to withstand harsh environments, with an enclosure rating of IP 67 and a temperature range of -20 to +50°C. It connects via a 4-pin M5 plug, ensuring secure and reliable connectivity. For further technical details, datasheets, catalogs, brochures, operating instructions, and CAD files are available for download.
- Sensor principle:
- Photoelectric diffuse sensor with Background Suppression
- Spot size [mm]:
- 1 x 3
- Series:
- F10 (21,1 x 14,6 x 8 mm)
- Working distance min. [mm]:
- 6
- Working distance max. [mm]:
- 30
- Velocity [Hz]:
- 1000
- Adjustment:
- Control input
- Light source:
- Laser, red (Class 1)
- Switching output:
- NPN
- Temperature range [°C]:
- -20 ... +50
- Connection type:
- Plug M5, 4-pin
- Enclosure rating:
- IP 67
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
