SensoPart FT 10-B-RLF2-PS-E4 Diffuse laser sensor with background suppression, fixed focus
Sensopart
The SensoPart FT 10-B-RLF2-PS-E4 is a high-performance diffuse laser sensor designed for precision detection with background suppression. It features a fixed focus with a working distance ranging from 6 to 30 mm, making it ideal for applications requiring accurate and reliable sensing. The sensor operates with a red laser light source (Class 1) and offers a spot size of 1 x 3 mm. With a velocity of 1000 Hz, it ensures rapid response times. The sensor is equipped with a PNP switching output and connects via a 4-pin M5 plug. It is built to withstand harsh environments with an IP 67 enclosure rating and operates efficiently within a temperature range of -20 to +50°C. The compact design, part of the F10 series, measures 21.1 x 14.6 x 8 mm. For further technical details, datasheets, catalogs, brochures, operating instructions, and CAD files are available through the provided links.
- Sensor principle:
- Photoelectric diffuse sensor with Background Suppression
- Spot size [mm]:
- 1 x 3
- Series:
- F10 (21,1 x 14,6 x 8 mm)
- Working distance min. [mm]:
- 6
- Working distance max. [mm]:
- 30
- Velocity [Hz]:
- 1000
- Adjustment:
- Control input
- Light source:
- Laser, red (Class 1)
- Switching output:
- PNP
- Temperature range [°C]:
- -20 ... +50
- Connection type:
- Plug M5, 4-pin
- Enclosure rating:
- IP 67
