SensoPart FT 10-RF1-NS-KM4 Photoelectric diffuse sensor with background suppression, fixed focus
Sensopart
The SensoPart FT 10-RF1-NS-KM4 is a compact photoelectric diffuse sensor with advanced background suppression, designed for precise detection tasks. It operates within a working distance of 1 to 15 mm, utilizing a red LED light source for reliable performance. The sensor features a fixed focus and an NPN switching output, making it suitable for various industrial applications. With a high velocity of 1000 Hz, it ensures rapid response times. The sensor is equipped with a 200 mm pigtail and a 4-pin M8 connector for easy integration. It is built to withstand harsh environments, boasting an IP 67 enclosure rating and a temperature range of -20 to +60°C. For further technical details, datasheets, and installation instructions, please refer to the provided links.
- Sensor principle:
- Photoelectric diffuse sensor with Background Suppression
- Series:
- F10 (21,1 x 14,6 x 8 mm)
- Working distance min. [mm]:
- 2
- Working distance max. [mm]:
- 15
- Velocity [Hz]:
- 1000
- Adjustment:
- Control input
- Light source:
- LED, red
- Switching output:
- NPN
- Temperature range [°C]:
- -20 ... +60
- Connection type:
- Pigtail, plug M8, 4-wire, 200 mm
- Enclosure rating:
- IP 67
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
