SensoPart FT 25-RA-170-NSU-M4M Miniature distance sensor
Sensopart
The SensoPart FT 25-RA-170-NSU-M4M Miniature Distance Sensor is a compact and efficient solution for precise distance measurement. With a working range of 30 to 200 mm and a resolution of 0.68 mm, this sensor utilizes red LED light and triangulation principles to deliver accurate results. It features a teach-in function and provides an analog voltage output ranging from 1 to 10 V. The sensor is equipped with an NPN switching output, which can auto-detect between PNP and NPN configurations. Its robust cubic design (34 x 20 x 12 mm) is complemented by a metal plug M8, 4-pin connection, ensuring durability and ease of installation. The sensor operates at a velocity of 1000 Hz and maintains performance across a temperature range of -20 to +60°C, with minimal temperature drift. Rated IP67 and IP69K, it is suitable for demanding environments. For further details, refer to the datasheet, catalog, brochure, operating instructions, and CAD files available through the provided links.
- Linearity [mm]:
- 2
- Sensor principle:
- Distance sensor with triangulation
- Series:
- F25 (34 x 20 x 12 mm)
- Working distance min. [mm]:
- 30
- Working distance max. [mm]:
- 200
- Velocity [Hz]:
- 1000
- Type:
- Cubic
- Light source:
- LED, red
- Switching output:
- NPN, PNP/NPN (auto detect)
- Amount of swithing outputs:
- 1
- Resolution [mm]:
- 0.68
- Repeatability [mm]:
- 1
- Temperature range [°C]:
- -20 ... +60
- Temperature drift [%]:
- 0,2 mm / K
- Measurement output:
- Analog (voltage)
- Connection type:
- Metal plug M8, 4-pin
- Enclosure rating:
- IP 67, IP69K
