SensoPart FT 25-RA-60-NSU-M4M Miniature distance sensor
Sensopart
The SensoPart FT 25-RA-60-NSU-M4M Miniature Distance Sensor is a compact and precise solution for distance measurement applications. With a working range of 20 to 80 mm and a resolution of 0.12 mm, this sensor utilizes red LED light and triangulation principles to deliver accurate results. It features a teach-in function and provides an analog output of 1 to 10 V, with auto-detecting PNP/NPN switching output. The sensor is housed in a robust cubic design (34 x 20 x 12 mm) with a metal plug M8, 4-pin connection, ensuring durability and reliability in harsh environments, as indicated by its IP67 and IP69K enclosure ratings. Operating efficiently at a velocity of 1000 Hz, it maintains performance across a temperature range of -20 to +60°C, with minimal temperature drift. For further technical details, datasheets, catalogs, brochures, operating instructions, and CAD files are available for download.
- Linearity [mm]:
- 0.4
- Sensor principle:
- Distance sensor with triangulation
- Series:
- F25 (34 x 20 x 12 mm)
- Working distance min. [mm]:
- 20
- Working distance max. [mm]:
- 80
- Velocity [Hz]:
- 1000
- Type:
- Cubic
- Light source:
- LED, red
- Switching output:
- PNP, PNP/NPN (auto detect)
- Amount of swithing outputs:
- 1
- Resolution [mm]:
- 0.12
- Repeatability [mm]:
- 0.4
- Temperature range [°C]:
- -20 ... +60
- Temperature drift [%]:
- 0,1 mm / K
- Measurement output:
- Analog (voltage)
- Connection type:
- Metal plug M8, 4-pin
- Enclosure rating:
- IP 67, IP69K
