SensoPart FT 25-RL-PS-KL4 Diffuse laser photoelectric proximity switch
Sensopart
The SensoPart FT 25-RL-PS-KL4 is a high-performance diffuse laser photoelectric proximity switch designed for precision and reliability. With a working distance ranging from 1 mm to 250 mm, this sensor utilizes a red Class 1 laser light source for accurate detection. It features a teach-in adjustment for easy setup and a PNP switching output for seamless integration into your system. The sensor operates at a velocity of 4000 Hz, ensuring rapid response times. It is equipped with a 150 mm pigtail and a 4-pin M12 connector for secure connections. Built to withstand harsh environments, it boasts an IP69K enclosure rating and operates efficiently within a temperature range of -20°C to +60°C. The compact F25 series design (34 x 20 x 12 mm) makes it ideal for space-constrained applications. For more detailed information, you can view the datasheet, catalog, brochure, operating instructions, and CAD files through the provided links.
- Sensor principle:
- Photoelectric diffuse sensor
- Series:
- F25 (34 x 20 x 12 mm)
- Working distance min. [mm]:
- 1
- Working distance max. [mm]:
- 250
- Velocity [Hz]:
- 4000
- Adjustment:
- Teach-in
- Light source:
- Laser, red (Class 1)
- Switching output:
- PNP
- Temperature range [°C]:
- -20 ... +60
- Connection type:
- Metal plug M8, 4-pin
- Enclosure rating:
- IP69K
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
