SensoPart FT 25-RLH-PS-M3 Diffuse laser sensor with background suppression
Sensopart
The SensoPart FT 25-RLH-PS-M3 is a high-performance photoelectric diffuse laser sensor designed with advanced background suppression technology. It operates within a working distance range of 4 to 120 mm, making it ideal for precise detection tasks. The sensor features a red Class 1 laser light source and offers a fast response time with a velocity of 1000 Hz. It is equipped with a teach-in adjustment for easy setup and configuration. The sensor's PNP switching output ensures reliable signal processing, while its robust metal plug M8, 3-pin connection type guarantees secure connectivity. Designed to withstand harsh environments, it operates efficiently within a temperature range of -20 to +60°C and boasts an IP69K enclosure rating for superior protection against dust and water ingress. For more detailed information, you can access the datasheet, catalog, brochure, operating instructions, and CAD files through the provided links.
- Sensor principle:
- Photoelectric diffuse sensor with Background Suppression
- Series:
- F25 (34 x 20 x 12 mm)
- Working distance min. [mm]:
- 4
- Working distance max. [mm]:
- 120
- Velocity [Hz]:
- 1000
- Adjustment:
- Teach-in
- Light source:
- Laser, red (Class 1)
- Switching output:
- PNP
- Temperature range [°C]:
- -20 ... +60
- Connection type:
- Metal plug M8, 3-pin
- Enclosure rating:
- IP69K
- Datasheet:
- View
- Catalog:
- View
- Brochure:
- View
- Operating Instructions:
- View
- CAD:
- View
