The SensoPart FT 50 RLA 40-F-L4S Distance Sensor is a high-precision device designed for accurate distance measurement within a range of 45 to 85 mm. Utilizing a red Class 1 laser as its light source, this sensor operates on the principle of triangulation to deliver reliable results with a resolution of 0.08 mm and repeatability of 0.2 mm. It features an analogue measurement output with a voltage range of 0 to 10 V, making it suitable for various industrial applications. The sensor is housed in a compact cubic design (50 x 50 x 17 mm) and is equipped with a 4-wire, 6-meter cable for easy connectivity via an M12 4-pin plug. With an enclosure rating of IP 67, it is well-protected against dust and water ingress, ensuring durability in challenging environments. The sensor operates efficiently within a temperature range of ±0 to +45°C, with minimal temperature drift of 0.018 mm/K. For further technical details, datasheets, catalogs, operating instructions, and CAD files are available through the provided links.
- Linearity [mm]:
- 0.9
- Sensor principle:
- Distance sensor with triangulation
- Series:
- F50 (50 x 50 x 17 mm)
- Working distance min. [mm]:
- 45
- Working distance max. [mm]:
- 85
- Velocity [Hz]:
- 400
- Type:
- Cubic
- Light source:
- Laser, red (Class 1)
- Resolution [mm]:
- 0.08 mm
- Repeatability [mm]:
- 0.2
- Temperature range [°C]:
- ±0 ... +45
- Temperature drift [%]:
- 0,018 mm / K
- Measurement output:
- Analog (voltage)
- Connection type:
- Cable, 4-wire, 6 m
- Enclosure rating:
- IP 67
