SensoPart FT 50 RLA 40-S-L4S Distance sensor
Sensopart
The SensoPart FT 50 RLA 40-S-L4S Distance Sensor is a high-precision device designed for accurate distance measurement within a range of 45 to 85 mm. Utilizing a red laser light source (Class 1), this sensor operates on the principle of triangulation to deliver reliable results with a resolution of 0.02 mm and repeatability of 0.1 mm. It features an analogue measurement output with a voltage range of 0 to 10 V, ensuring seamless integration into various systems. The sensor is housed in a compact cubic design (50 x 50 x 17 mm) and is equipped with a robust M12 4-pin plug for secure connections. With an enclosure rating of IP 67, it is well-suited for challenging environments, maintaining performance across a temperature range of ±0 to +45°C with minimal temperature drift. The sensor's linearity is rated at 0.9 mm, and it operates at a velocity of 40 Hz, making it ideal for dynamic applications. For further technical details, datasheets, catalogs, operating instructions, and CAD files are available for download.
- Linearity [mm]:
- 0.9
- Sensor principle:
- Distance sensor with triangulation
- Series:
- F50 (50 x 50 x 17 mm)
- Working distance min. [mm]:
- 45
- Working distance max. [mm]:
- 85
- Velocity [Hz]:
- 40
- Type:
- Cubic
- Light source:
- Laser, red (Class 1)
- Resolution [mm]:
- 0.02
- Repeatability [mm]:
- 0.1
- Temperature range [°C]:
- ±0 ... +45
- Temperature drift [%]:
- 0,018 mm / K
- Measurement output:
- Analog (voltage)
- Connection type:
- Plug M12, 4-pin
- Enclosure rating:
- IP 67
- Datasheet:
- View
- Catalog:
- View
- Operating Instructions:
- View
- CAD:
- View
