SensoPart IMT 4-S-B2-PSL-KM3 Inductive sensor M4 / standard switching distance
Sensopart
The SensoPart IMT 4-S-B2-PSL-KM3 is a high-performance inductive sensor designed for precision and reliability. Encased in a compact M4 housing, this sensor offers a standard switching distance with a sensing range of Sn= 1 mm. It features a PNP/NO output and is equipped with a 200 mm pig tail leading to an M8 3-pin plug, ensuring easy connectivity. The sensor supports IO-Link 1.1, providing various parameterization options for enhanced flexibility and integration into complex systems. Ideal for applications requiring precise detection in tight spaces, the SensoPart IMT 4-S-B2-PSL-KM3 is a versatile solution for modern automation needs.
- Rated operating distance Sn [mm]:
- 1
- Repeatability [mm]:
- 0.02
- Interface:
- IO-Link
- Velocity [Hz]:
- ? 3000
- Mounting:
- Flush
- Housing:
- Stainless steel
- Series:
- M04
- Type:
- Barrel type
- Switching output:
- PNP
- Temperature range [°C]:
- -25 ... +70
- Connection type:
- Metal plug M8, 3-pin
- Enclosure rating:
- IP 67
- Datasheet:
- View
- Catalog:
- View
- QN-QUOTE-REQUEST:
- true
