SMC 10-SS5V2-10FD2-06B-C8 | Clean Room SV2000 Valve Manifold 6-Station D-Sub Connector Tie-Rod Base 1/2" Port
SMC
$258.85
The SMC 10-SS5V2-10FD2-06B-C8 is a clean room specification solenoid valve manifold from the SV2000 series with D-sub connector and 6 valve stations. Part number decoded: SS5V2 = SV2000 series manifold, 10FD2 = D-sub connector type 2 (different pin configuration or wiring scheme from FD1), 06B = 6-station with B-type port arrangement, C8 = 1/2" port size. The 1/2" ports represent the largest standard port option in the SV2000 manifold range, providing maximum flow capacity per station.
The combination of SV2000 large valve bodies with 1/2" ports creates a high-flow manifold assembly for demanding clean room applications involving large-bore cylinders (40mm+), high-speed cycling requirements, and large-volume actuators where airflow must be maximized to achieve target cycle times. The FD2 D-sub connector variant provides a specific pin assignment that may differ from FD1 verify the pinout matches your PLC wiring standard before ordering.
The SS5V2-10FD2-06B-C8 is the high-flow configuration at 6 stations. For more stations at 1/2" port, 08B-C8 and 10B-C8 extend the manifold. For smaller ports when maximum flow is unnecessary, C4 (1/4") and C6 (3/8") reduce manifold size. For even higher flow, the SS5V3 (SV3000) provides the largest SV valve bodies. For serial communication, the SS5V2-W EX260/EX600 integrated versions eliminate the D-sub connector. Clean series (10-) fluorine grease, Particle Grade 1. RoHS compliant.
- Series:
- 10-SS5V2/SV2000 (Clean Room)
- Product Type:
- Solenoid Valve Manifold
- Stations:
- 6
- Electrical:
- D-Sub Connector (10FD2)
- Base Type:
- Tie-Rod
- Port Size:
- 1/2" (C8)
- Clean Room Grade:
- Particle Generation Grade 1
- Certifications:
- RoHS
