SMC 11-CXSL25TN-50-Y59A | Clean Room Dual Rod Cylinder CXS Series 25mm Bore 50mm Stroke Non-Rotating Table Y59A Switch
SMC
$404.60
The SMC 11-CXSL25TN-50-Y59A is a clean room specification dual rod cylinder from the CXS series with TN non-rotating table and Y59A auto-switch. Part number decoded: CXS = CXS dual rod slide table, L = body type, 25 = 25mm bore, TN = non-rotating table variant (T = table type, N = non-rotating), 50 = 50mm stroke, Y59A = specific auto-switch bracket and sensor configuration.
The TN (non-rotating table) variant adds an additional anti-rotation mechanism to the already-guided CXS platform. While the standard CXS dual rod design inherently resists rotation through its two guide shafts, the TN option provides an enhanced constraint that eliminates any residual angular play between the guide rods and bushings. This is critical when the slide table carries precision tooling, optical sensors, or alignment fixtures where even micro-degrees of rotational play would exceed the application's angular tolerance specification.
The CXSL25TN-50-Y59A provides the highest rigidity CXS configuration at 25mm bore with the Y59A switch for position feedback. For the standard CXS at 25mm bore without the TN enhancement, the CXSL25-50 provides base guided motion. For TN non-rotating at different bore sizes, the option is available across the CXS range. At 25mm bore, the cylinder generates approximately 29N at 0.6 MPa, suited for medium-duty guided slide operations. For even higher rigidity, the MGF guide table series provides a different guided platform. Clean series (11-) fluorine grease. RoHS compliant.
- Series:
- 11-CXS (Clean Room)
- Cylinder Type:
- Dual Rod Slide Table
- Action:
- Double-Acting
- Guide:
- Ball Bushing
- Bore:
- 25mm
- Stroke:
- 50mm
- Feature:
- TN Non-Rotating Table
- Auto-Switch:
- Y59A
- Clean Room Grade:
- Enhanced (11-)
- Certifications:
- RoHS
