SMC 22-MHL2-10D1 22-MHL2 Series Copper Fluorine And Silicon-free + Low Particle Generation Parallel Style Wide Opening Air Gripper

SMC 22-MDHR2-30R-M9BL | Copper/Fluorine/Silicon-Free 2-Finger Rotary Air Gripper MHR2 Series Size 30 Auto-Switch

SMC
SKU:
22-MHL2-10D1
Availability:
Factory Stock
$681.40
Condition:
New
Current Stock:
Description

The SMC 22-MDHR2-30R-M9BL is a copper, fluorine, and silicon-free 2-finger rotary actuated air gripper from the MHR2 series. Part number decoded: MDHR2 = MHR2 2-finger rotary gripper (D = double acting), 30 = size 30 (largest MHR2), R = R-type finger configuration, M9BL = pre-mounted auto-switch (M9B with L lead wire). The 22- prefix designates Cu/F/Si-free construction.

Size 30 is the largest MHR2 rotary gripper, delivering maximum gripping force and jaw opening. The rotary finger mechanism opens and closes the gripping jaws by rotating them, providing a compact gripping profile. The Cu/F/Si-free construction ensures no trace copper, fluorine, or silicon contamination from the gripper mechanism, essential when handling semiconductor wafers, optical substrates, or process-sensitive components in front-end fabrication.

The 22-MDHR2-30R-M9BL provides Cu/F/Si-free rotary gripping at the maximum MHR2 size. For the standard clean room MHR2 (11-), the 11-MDHR2-10E provides the base clean room option. For Cu/F/Si-free parallel grippers, the 22-MHL2 provides wide-opening parallel jaw options. For Cu/F/Si-free angular grippers, the 22-MHZ2 provides parallel jaw angular options. RoHS compliant.

Additional Information
Series:
22-MHR2 (Cu/F/Si-Free)
Gripper Type:
2-Finger Rotary
Action:
Double-Acting
Size:
30 (Largest)
Finger:
R-Type
Auto-Switch:
M9BL Pre-Mounted
Material:
Copper Fluorine Silicon Free
Certifications:
RoHS
