SMC 22-MHL2-10D-M9N | Copper/Fluorine/Silicon-Free Parallel Wide Opening Air Gripper MHL2 Series Size 10 Auto-Switch
SMC
$383.85
The SMC 22-MHL2-10D-M9N is a copper, fluorine, and silicon-free parallel wide opening air gripper with pre-mounted M9N auto-switch. Part number decoded: MHL2 = MHL2 parallel wide opening gripper, 10 = size 10, D = double acting, M9N = pre-mounted auto-switch. The 22- prefix designates Cu/F/Si-free construction.
This variant adds the M9N auto-switch to the MHL2-10D base unit, providing grip confirmation feedback to the PLC. The M9N switch detects the gripper jaw position through a magnetic piston, confirming whether the gripper is open or closed. This is essential for automated pick-and-place sequences where the PLC must verify successful gripping before moving the robot arm or gantry.
The 22-MHL2-10D-M9N provides the sensored Cu/F/Si-free wide opening gripper. For the D1 jaw configuration without switch, the 22-MHL2-10D1 provides an alternative jaw type. For NPN M9P output instead of M9N, the M9P variant may be available. For the standard clean room grade (11-), the 11-MHL2-10D provides the base option. For Cu/F/Si-free angular grippers, the 22-MHZ2-10D2 provides the angular jaw alternative. RoHS compliant.
- Series:
- 22-MHL2 (Cu/F/Si-Free)
- Gripper Type:
- Parallel Wide Opening
- Action:
- Double-Acting
- Size:
- 10
- Auto-Switch:
- M9N Pre-Mounted
- Material:
- Copper Fluorine Silicon Free
- Certifications:
- RoHS
