SMC 22-MSQB20R | Copper/Fluorine/Silicon-Free Rotary Table MSQ Series Size 20 B-Type R-Mechanism
SMC
$247.10
The SMC 22-MSQB20R is a copper, fluorine, and silicon-free rotary table from the MSQ series in size 20. Part number decoded: MSQ = MSQ rotary table, B = B-type body configuration, 20 = size 20, R = R-type vane mechanism. The 22- prefix designates Cu/F/Si-free construction.
The B-type body at size 20 provides a different mounting interface from the A-type used in the size 10 MSQA variant. Size 20 doubles the table capacity and torque output from size 10, handling heavier workpieces and larger tooling fixtures. The R-type vane mechanism provides smooth rotary motion with cushioned end-of-stroke. Cu/F/Si-free construction ensures the highest material purity for semiconductor applications.
The 22-MSQB20R provides Cu/F/Si-free mid-range rotary indexing. For the smaller Cu/F/Si-free MSQ, the 22-MSQA10R provides size 10. For the standard clean room MSQ at size 20, the 11-MSQA20R provides the base clean room option. For auto-switch capability, add brackets or M9P/M9B suffixes. For Cu/F/Si-free grippers, the 22-MDHR2 and 22-MHL2 series provide Cu/F/Si-free gripping. RoHS compliant.
- Series:
- 22-MSQ (Cu/F/Si-Free)
- Actuator Type:
- Rotary Table
- Size:
- 20
- Body:
- B-Type
- Mechanism:
- R-Type (Vane)
- Material:
- Copper Fluorine Silicon Free
- Certifications:
- RoHS
