SMC CLK2GA40TN-75YAK-B2 CLK2G/CLK2P Series Clamp Cylinder With Lock With Magnetic Field Resistant Auto Switch Rod Mounting
SMC
$500.00
The SMC CLK2GA40TN-75YAK-B2 is a high-performance clamp cylinder from the CLK2G/CLK2P Series, designed to enhance operational efficiency in industrial applications. This innovative clamp cylinder features a single-directional lock, allowing it to maintain a clamped or unclamped state even when air supply pressure drops or residual pressure is released. Its magnetic field resistant auto switch rod mounting ensures reliable performance in challenging environments. Additionally, the built-in cushion valve and plug eliminate overhang from the tube cover, streamlining operations and improving overall efficiency. Ideal for applications requiring precise and secure clamping, this clamp cylinder is a robust and reliable choice for modern industrial needs.
- Type:
- Built-In Standard Magnet Type With Magnetic Field Resistant Auto Switch
- Clevis Width:
- 16.5 mm
- Bore Size:
- Bore Size 40 mm
- Port Type:
- NPT
- Cylinder Stroke:
- Standard Stroke 75 mm
- Cylinder Stroke:
- Double Knuckle Joint M6 With Tap
- Option:
- Pedestal For 75, 100, 150 Strokes Only
- Locking Direction:
- Retraction Locking
- Port/Bypass Piping Position:
- Port Position:Left
- Switch Mounting Rod Position:
- Top/None
- Auto Switch:
- Without Auto Switch Built-in Magnet Without Switch Mounting Rod
- Number Of Auto Switches:
- 2 pcs. Or None
- Made To Order:
- Standard
