SMC EX500-GEN2 Serial Transmission System
- SKU:
- EX500-GEN2
- Condition:
- New
- Availability:
- In stock: 47
- Communication Protocol:
- EN2 [EtherNet/IP, Gateway Distributed System2 (128 Points)]
Description
EX500, Decentralized Serial Wiring, GW System
EX500 a gateway unit to connect EtherNet/IP , DeviceNet , and Profibus DP to SMC valves and digital inputs for sensors for distributed I/O system. Each gateway can control up to 8 valve manifolds and 8 input blocks, with maximum of 128 outputs and 128 inputs. EX500-GEN2 supports Device level Ring (DLR) and EtherNet/IP Quick Connect function. The gateway module has IP65 protection while valve modules and input blocks have IP67 protection ensuring protection against dust and washdown environment.
- GW system, 4 branches- Valve input unit manifolds can be connected around the GW unit
- Contol up to 128 digital outputs 128 digital inputs
- GW unit, input unit manifold: IP65
- Valve manifold including SI unit: IP67
-
