SMC KQ2Z09-35NS KQ2Z Series One-Touch Fitting Branch Universal Male Elbow with Sealant

The SMC KQ2Z09-35NS KQ2Z Series Inch Size One-touch Fittings Branch Universal Male Elbow With Sealant is engineered for precision and reliability in pneumatic systems. This component is designed to operate efficiently in vacuum conditions down to -100 kPa, making it ideal for a wide range of industrial applications. With a comprehensive selection of 51 body models, this fitting offers versatility to meet specific system requirements. The thread material is available in two types: untreated brass and brass with an electroless nickel plating, providing options for enhanced corrosion resistance and durability. The KQ2Z09-35NS fitting accommodates both circular and oval tubing with a variety of outer diameters. For circular tubing, it supports metric sizes of 2, 3.2, 4, 6, 8, 10, 12, and 16 mm, as well as inch sizes of 1/8", 5/32", 3/16", 1/4", 5/16", 3/8", and 1/2". For oval tubing, it supports metric sizes of 3.2, 4, and 6 mm, and inch sizes of 1/8", 5/32", and 3/16". The connection thread options are extensive, including Metric (M3, M5, M6), R/Rc (1/8, 1/4, 3/8, 1/2), G (1/8, 1/4, 3/8, 1/2), NPT (10-32UNF, 1/16, 1/8, 1/4, 3/8, 1/2), and Uni (1/8, 1/4, 3/8, 1/2). This ensures compatibility with a wide range of existing systems and components. The seal method is robust, featuring options for sealant/gasket seal, face seal, and gasket seal for Uni threads, ensuring leak-proof connections and reliable performance under demanding conditions. Optimize your pneumatic systems with the SMC KQ2Z09-35NS, a fitting that combines flexibility, durability, and precision engineering. Ideal for engineers and manufacturing professionals seeking high-quality components for efficient and reliable system integration.
