SMC LVD20-V03N-F LVD-F/FN Series Air Operated Chemical Liquid Valve Compact Type Insert Bushing,Integral Fitting Type
SMC
$209.00
The SMC LVD20-V03N-F LVD-F/FN Series Air Operated Chemical Liquid Valve is a compact and efficient solution for managing chemical liquids. This valve features an innovative design with an integral fitting type and insert bushing, making it ideal for space-saving applications. The actuator is crafted from PVDF resin, offering enhanced durability and chemical resistance. The body is constructed from new PFA, while the diaphragm is made of PTFE, and the actuator section is composed of PPS, ensuring robust performance in demanding environments. One of the standout features of this valve is its versatile piping connections, which can be configured from four different directions, providing flexibility in installation. Additionally, the valve offers up to a 29% reduction in dimensions on the piping side compared to previous models, making it a superior choice for compact installations.
- Body Class:
- Body Class:2
- Valve Type:
- N.C.
- Fitting Type:
- LQ1
- Applicable Tubing Size:
- Metric Size:3X2
- Port B (OUT) Different Dia. Size:
- Ports A & B Same Size
- Pilot Port Type:
- NPT1/8
- Pilot Port Position:
- Position 1
- Material:
- Body:PFA
- Option:
- None
