SMC

SMC ZH15DLA-09-11-11S ZH Series Body Ported Type Vacuum Ejector

(No reviews yet) Write a Review
SKU:
ZH15DLA-09-11-11S
MPN:
ZH15DLA-09-11-11S
Condition:
New
Nozzle Diameter:
Φ1.5 mm
Body:
Body Ported
Vacuum Pressure Reached:
-48kPa (ZH05 To 13D A)
SUP. Port Size:
Φ5/16" One-touch Fitting
VAC. Port Size:
Φ3/8" One-touch Fitting
EXH. Port Size:
Φ3/8" One-touch Fitting
Accessory:
With Standard bracket,With Silencer
  • SMC ZH15DLA-09-11-11S Vacuum Ejector
  • SMC ZH15DLA-09-11-11S ZH Series Body Ported Type Vacuum Ejector
$27.75

Description

ZH Series Body Ported Type Vacuum Ejector

  • Nozzle sizes: Φ1.5, Φ1.8, and Φ2.0 have been added to the box type.[New];
  • Compact and lightweight; Overall length: Max. 11% reduction; Port height: Max. 25% reduction; Volume: Max. 39% reduction;
  • 4 mounting types;
  • A silencer and standard bracket are available. (Body ported type only)
    • View AllClose
