SMC

SMC ZM101HT-K5L ZM Series Vacuum Ejector With Valve And Switch

(No reviews yet) Write a Review
SKU:
ZM101HT-K5L
MPN:
ZM101HT-K5L
Condition:
New
Nozzle Diameter:
1.0 mm
Body Style:
Unit: Valve + With Standard Silencer
Vacuum Port Location:
Side/Bottom Entry
Standard Supply Pressure:
0.5 MPa
Thread Type:
NPTF
Combination Of Supply Valve And Release Valve:
Supply Valve (N.C.), And Release Valve
Pilot Valve:
DC: 1 W (With Indicator Light: 1.05 W)
Solenoid Valve Rated Voltage:
24 VDC
Electrical Entry:
L Plug Connector, With 0.3 m Lead Wire
Light/Surge Voltage Suppressor:
None
Manual Override:
Non-Locking Push Type
Vacuum Switch Model:
Without Switch
Vacuum Switch Electrical Entry:
Grommet Type, With 0.6 m Lead Wire (ZSE1)
Release Flow Rate Adjusting Needle:
Without Lock Nut
Made To Order:
Standard
CE/UKCA-compliant:
-
  • SMC ZM101HT-K5L Vacuum Ejector
  • SMC ZM101HT-K5L ZM Series Vacuum Ejector With Valve And Switch
$177.55

Description

ZM Series Vacuum Ejector With Valve And Switch

  • Valves and switches are unitized;
  • Adaptable for manifold application;
  • Maximum absorption flow rate is increased by 40%;
  • Maximum vacuum pressure -84 kPa
