Turck B 8141-0/Pg 9/Asi U2-13620
Turck
$32.20
Manufacturer's Part Number: U2-13620
AS-Interface Field Wireable. M12 Connection. Ident. no.: U2-13620. Straight Female M12 eurofast Field Wireable. 4 pins. Screw termination. Plastic housing. Screw terminal Wire Termination. Plastic housing. M12, Female, Straight, 4-pin. PG9 screw-in thread. Cable feedthrough 6.0
8.0 mm
- Application:
- Data
- Fieldbus Protocol:
- AS-Interface
- Connector A:
- Female, M12 ?ù 1, Straight, A-code
- Number of contacts:
- 4
- Connection mode:
- Screw/clamp connection
- Housing material:
- Plastic, PA
- Coupling nut/screw material:
- Plastic, PA
- Acceptable cable diameter:
- 6?à8 mm
- Core cross-section/Clamping ability:
- 0.14?à18 mm??
- Voltage:
- 250 V
- Current:
- 4 A
- Approvals:
- UL Recognized, RoHS
