Manufacturer's Part Number: 2503550
Capacitive Sensor. Ident. no.: 2503550. M18 1 threaded barrel. Plastic, PVDF. Fine adjustment via potentiometer. DC 3-wire, 1065 VDC. NO contact, NPN output. Cable connection
- Design:
- Threaded barrel
- Construction size:
- M18 x 1
- Rated switching distance:
- 7.5 mm
- Output function:
- NO contact, NPN
- Electrical connection:
- Cable
- Cable length (L):
- 2.0 m
- Housing material:
- Plastic, PVDF
- Ambient temperature:
- -25 +70 °C
- Protection class:
- IP67
- Approvals:
- UL
