Turck Bi1-Eh04-An6X-0.3-Rs4T Inductive 4609699
Turck
$204.10
Manufacturer's Part Number: 4609699
Inductive Sensor. Ident. no.: 4609699. Smooth barrel, Ã 4 mm. Stainless steel 1.4305 (AISI 303). DC 3-wire, 10
30 VDC. NO contact, NPN output. Pigtail with M12 Ã 1 connector
- Design:
- Smooth barrel
- Construction size:
- Ø 4 mm
- Rated switching distance:
- 1 mm
- Mounting:
- Flush
- Operating voltage:
- 10 30 VDC
- Output function:
- NO contact, NPN
- Switching frequency:
- 3.0 kHz
- Electrical connection:
- Cable with connector, M12 × 1
- Cable length (L):
- 0.30 m
- Housing material:
- Stainless steel, 1.4305 (AISI 303)
- Ambient temperature:
- -25 +70 °C
- Protection class:
- IP67
- Catalog:
- View
- Datasheet:
- View
