Name: Turck Bi10U-Q14-An6X2 Inductive 1608710
Brand: Turck
SKU: BI10U-Q14-AN6X2
Price: 140.9 USD
Availability: InStock

Turck Bi10U-Q14-An6X2 Inductive 1608710

(No reviews yet) Write a Review

SKU:

BI10U-Q14-AN6X2

MPN:

1608710

Condition:

New

Availability:

Factory Stock: 3

Design:

Rectangular

Construction size:

52 x 30 x 14 mm, Q14

Rated switching distance:

10 mm

Mounting:

Flush

Operating voltage:

10?à30 VDC

Output function:

NO contact, NPN

Switching frequency:

0.250 kHz

Electrical connection:

Cable

Cable length (L):

2.0 m

Housing material:

Plastic, PBT-GF30-V0

Ambient temperature:

-30?à+85 ??C

Protection class:

IP67

Special features:

uprox+, Factor 1, Resistant to magnetic fields

Flyer:

View

Catalog:

View

Datasheet:

View

Description

Inductive Sensor. Ident. no.: 1608710. Rectangular, height 14 mm. Active face on top. Plastic, PBT GF30 V0. Factor 1 for all metals. Resistant to magnetic fields. Extended temperature range. High switching frequency. DC 3-wire, 1030 VDC. NO contact, NPN output. Cable connection
