Turck

Turck Bi15-Em30-An45Xld-0.2-Rs4T Inductive 1584071

(No reviews yet) Write a Review
SKU:
BI15-EM30-AN45XLD-0.2-RS4T
MPN:
1584071
Condition:
New
Design:
Threaded barrel
Construction size:
M30 x 1.5
Rated switching distance:
15 mm
Mounting:
Flush
Operating voltage:
8.6…65 VDC
Output function:
NO contact, NPN
Switching frequency:
0.50 kHz
Electrical connection:
Cable with connector, M12 × 1
Cable length (L):
0.20 m
Housing material:
Stainless steel, 1.4301 (AISI 304)
Ambient temperature:
-40…+85 °C
Protection class:
IP68/IP69K
Approvals:
E1 type approval
Special features:
Commercial vehicle specification, Sn +
  • Turck Bi15-Em30-An45Xld-0.2-Rs4T Inductive 1584071
  • Turck Bi15-Em30-An45Xld-0.2-Rs4T Inductive sensor
$179.50

Description

Inductive Sensor. For Use in Vehicle Board Nets. Ident. no.: 1584071. M30 1.5 threaded tube. Stainless steel, 1.4301. For vehicle board nets, 12 V and 24 V. Increased interference immunity 100 V/m radiated acc. ISO 11452-4 and 100 mA BCI acc. to ISO 11452-2. Load-dump protection acc. to DIN ISO 7637-2 (SAE J 113-11). Extended temperature range. High protection class IP68/IP69K. Protection against salt spray and rapid temperature change. Laser engraved label, permanently legible. DC 3-wire, 8.465 VDC. NO contact, NPN output. Pigtail with male end M12 x 1. E1 type approval from German federal office for motor vehicles
