Turck Bi2-Eg08-An6X-0.2-Psg3M Inductive 4602186
Turck
$181.40
Manufacturer's Part Number: 4602186
Inductive Sensor. With Increased Switching Distance. Ident. no.: 4602186. Gewinderohr, M8 x 1. Edelstahl, 1.4305 (AISI 303). Large sensing range. DC 3-wire, 10
30 VDC. NO contact, NPN output. Pigtail with male end M8 x 1
- Design:
- Threaded barrel
- Construction size:
- M8 x 1
- Rated switching distance:
- 2 mm
- Mounting:
- Flush
- Operating voltage:
- 10 30 VDC
- Output function:
- NO contact, NPN
- Switching frequency:
- 3.0 kHz
- Electrical connection:
- Cable with connector, Ø 8 mm
- Cable length (L):
- 0.20 m
- Housing material:
- Stainless steel, 1.4305 (AISI 303)
- Ambient temperature:
- -25 +70 °C
- Protection class:
- IP67
- Special features:
- Sn +
- Catalog:
- View
- Datasheet:
- View
