Turck Bi2U-Eg08-Ap6X-0.3-Psg3M Inductive 46020321
Manufacturer's Part Number: 46020321
Inductive Sensor. With Extended Switching Distance. Ident. no.: 46020321. Threaded barrel, M8 x 1. Stainless steel, 1.4427 SO. Factor 1 for all metals. Protection class IP68. Resistant to magnetic fields. Large switching distance. High switching frequency. Recessed mountable. DC 3-wire, 10
30 VDC. NO contact, PNP output. Pigtail with male end M8 x 1
- Design:
- Threaded barrel
- Construction size:
- M8 x 1
- Rated switching distance:
- 2 mm
- Mounting:
- Flush
- Operating voltage:
- 10?à30 VDC
- Output function:
- NO contact, PNP
- Switching frequency:
- 1.0 kHz
- Electrical connection:
- Cable with connector, M8 ?ù 1
- Cable length (L):
- 0.30 m
- Housing material:
- Stainless steel, 1.4427 SO
- Ambient temperature:
- -30?à+85 ??C
- Protection class:
- IP68
- Special features:
- uprox+, Factor 1, Resistant to magnetic fields
- Catalog:
- View
- Datasheet:
- View
