Turck Bi3-M18-Ap6X/S903 Inductive 4607140
Turck
$175.80
Manufacturer's Part Number: 4607140
Inductive Sensor. Ident. no.: 4607140. Threaded barrel, M18 x 1. Chrome-plated brass. Hysteresis always below 0.1 mm. DC 3-wire, 10
30 VDC. NO contact, PNP output. Cable connection
- Design:
- Threaded barrel
- Construction size:
- M18 x 1
- Rated switching distance:
- 3 mm
- Mounting:
- Flush
- Operating voltage:
- 10 30 VDC
- Output function:
- NO contact, PNP
- Switching frequency:
- 0.50 kHz
- Electrical connection:
- Cable
- Cable length (L):
- 2.0 m
- Housing material:
- Metal, CuZn, Chrome-plated
- Ambient temperature:
- -30 +70 °C
- Protection class:
- IP67
- Catalog:
- View
- Datasheet:
- View
